Intel Celeron N4500
The Intel Celeron N4500 processor is a budget-friendly option for basic laptop computing needs. With a 10nm technology, it offers improved power efficiency and performance compared to its predecessors. The dual-core processor has a base frequency of 1.1 GHz, which is suitable for everyday tasks such as web browsing, word processing, and multimedia consumption.
The integrated Intel UHD Graphics provide decent visuals for casual gaming and video streaming, although it may struggle with more demanding tasks like graphic design or video editing. The 4MB L3 cache helps to improve overall system responsiveness, while the low 6W TDP ensures minimal power consumption and heat generation.
In terms of benchmark performance, the Celeron N4500 scores an impressive 515 in Geekbench 6 single-core and 882 in multi-core tests. This indicates smooth operation for light multitasking and productivity workloads.
Overall, the Intel Celeron N4500 is a suitable choice for budget laptops designed for everyday use. While it may not be well-suited for intensive tasks, it offers a good balance of performance and energy efficiency for basic computing needs.
Read more...
Basic
Label Name
Intel
Platform
Laptop
Launch Date
January 2021
Model Name
?
The Intel processor number is just one of several factors - along with processor brand, system configurations, and system-level benchmarks - to be considered when choosing the right processor for your computing needs.
N4500
Code Name
Jasper Lake
CPU Specifications
Total Cores
?
Cores is a hardware term that describes the number of independent central processing units in a single computing component (die or chip).
2
Total Threads
?
Where applicable, Intel® Hyper-Threading Technology is only available on Performance-cores.
2
Performance-cores
2
Performance-core Base Frequency
1.1 GHz
L1 Cache
32K per core
L2 Cache
384K per core
L3 Cache
4MB shared
Unlocked Multiplier
No
Multiplier
11x
Bus Frequency
100MHz
CPU Socket
?
The socket is the component that provides the mechanical and electrical connections between the processor and motherboard.
BGA-1338
Technology
?
Lithography refers to the semiconductor technology used to manufacture an integrated circuit, and is reported in nanometer (nm), indicative of the size of features built on the semiconductor.
10 nm
TDP
6 W
Max. Operating Temperature
?
Junction Temperature is the maximum temperature allowed at the processor die.
105 °C
PCIe Version
?
PCI Express is a high-speed serial computer expansion bus standard used for connecting high-speed components, replacing older standards such as AGP, PCI, and PCI-X. It has gone through multiple revisions and improvements since its initial release. PCIe 1.0 was first introduced in 2002, and in order to meet the growing demand for higher bandwidth, subsequent versions have been released over time.
3.0
Instruction Set
?
The instruction set is a hard program stored inside the CPU that guides and optimizes CPU operations. With these instruction sets, the CPU can run more efficiently. There are many manufacturers that design CPUs, which results in different instruction sets, such as the 8086 instruction set for the Intel camp and the RISC instruction set for the ARM camp. x86, ARM v8, and MIPS are all codes for instruction sets. Instruction sets can be extended; for example, x86 added 64-bit support to create x86-64. Manufacturers developing CPUs that are compatible with a certain instruction set need authorization from the instruction set patent holder. A typical example is Intel authorizing AMD, enabling the latter to develop CPUs compatible with the x86 instruction set.
x86-64
Memory Specifications
Memory Type
?
Intel® processors come in four different types: Single Channel, Dual Channel, Triple Channel, and Flex Mode. Maximum supported memory speed may be lower when populating multiple DIMMs per channel on products that support multiple memory channels.
DDR4-2933
Max Memory Size
?
Max memory size refers to the maximum memory capacity supported by the processor.
32GB
Memory Channels
?
The number of memory channels refers to the bandwidth operation for real world application.
2
Max Memory Bandwidth
?
Max Memory bandwidth is the maximum rate at which data can be read from or stored into a semiconductor memory by the processor (in GB/s).
45.8 GB/s
ECC Memory Support
No
GPU Specifications
Integrated Graphics Model
?
An integrated GPU refers to the graphics core that is integrated into the CPU processor. Leveraging the processor's powerful computational capabilities and intelligent power efficiency management, it delivers outstanding graphics performance and a smooth application experience at a lower power consumption.
True
GPU Base Frequency
350 MHz
GPU Max Dynamic Frequency
750 MHz
Execution Units
?
The Execution Unit is the foundational building block of Intel’s graphics architecture. Execution Units are compute processors optimized for simultaneous Multi-Threading for high throughput compute power.
16
Graphics Performance
0.24 TFLOPS
Miscellaneous
PCIe Lanes
8
Benchmarks
Cinebench R23
Single Core
Score
458
Cinebench R23
Multi Core
Score
688
Geekbench 6
Single Core
Score
515
Geekbench 6
Multi Core
Score
882
Geekbench 5
Single Core
Score
578
Geekbench 5
Multi Core
Score
1071
Passmark CPU
Single Core
Score
1379
Passmark CPU
Multi Core
Score
1980
