Intel Celeron N4000
About processor
The Intel Celeron N4000 is a low-power processor designed for use in budget-friendly laptops. Built on the 14nm Gemini Lake architecture, this dual-core processor has a base frequency of 1.1 GHz and a thermal design power of 5W, making it suitable for efficient and fanless laptop designs.
While the N4000 is not meant for heavy multitasking or demanding applications, it handles everyday productivity tasks with ease. Its integrated graphics allow for basic multimedia tasks, such as streaming videos and casual gaming. With a Geekbench 6 single-core score of 339 and a multi-core score of 474, the N4000 delivers modest performance for its intended usage.
One of the key advantages of the N4000 is its low power consumption, making it ideal for portable devices with long battery life. However, users looking for more processing power may find the N4000 lacking, particularly when it comes to resource-intensive applications or multitasking.
Overall, the Intel Celeron N4000 is a competent processor for light workloads and basic computing needs, making it a suitable choice for budget laptops aimed at casual users or students. Its energy efficiency and integrated graphics make it a solid option for those seeking an affordable and portable laptop solution.
Basic
Label Name
Intel
Platform
Laptop
Launch Date
December 2017
Model Name
?
The Intel processor number is just one of several factors - along with processor brand, system configurations, and system-level benchmarks - to be considered when choosing the right processor for your computing needs.
N4000
Code Name
Gemini Lake
CPU Specifications
Total Cores
?
Cores is a hardware term that describes the number of independent central processing units in a single computing component (die or chip).
2
Total Threads
?
Where applicable, Intel® Hyper-Threading Technology is only available on Performance-cores.
2
Performance-cores
2
Performance-core Base Frequency
1.1 GHz
L1 Cache
48K per core
L2 Cache
4MB per core
Unlocked Multiplier
No
CPU Socket
?
The socket is the component that provides the mechanical and electrical connections between the processor and motherboard.
BGA-1090
Technology
?
Lithography refers to the semiconductor technology used to manufacture an integrated circuit, and is reported in nanometer (nm), indicative of the size of features built on the semiconductor.
14 nm
TDP
5 W
Max. Operating Temperature
?
Junction Temperature is the maximum temperature allowed at the processor die.
105 °C
PCIe Version
?
PCI Express is a high-speed serial computer expansion bus standard used for connecting high-speed components, replacing older standards such as AGP, PCI, and PCI-X. It has gone through multiple revisions and improvements since its initial release. PCIe 1.0 was first introduced in 2002, and in order to meet the growing demand for higher bandwidth, subsequent versions have been released over time.
2.0
Instruction Set
?
The instruction set is a hard program stored inside the CPU that guides and optimizes CPU operations. With these instruction sets, the CPU can run more efficiently. There are many manufacturers that design CPUs, which results in different instruction sets, such as the 8086 instruction set for the Intel camp and the RISC instruction set for the ARM camp. x86, ARM v8, and MIPS are all codes for instruction sets. Instruction sets can be extended; for example, x86 added 64-bit support to create x86-64. Manufacturers developing CPUs that are compatible with a certain instruction set need authorization from the instruction set patent holder. A typical example is Intel authorizing AMD, enabling the latter to develop CPUs compatible with the x86 instruction set.
x86-64
Memory Specifications
Memory Type
?
Intel® processors come in four different types: Single Channel, Dual Channel, Triple Channel, and Flex Mode. Maximum supported memory speed may be lower when populating multiple DIMMs per channel on products that support multiple memory channels.
DDR4-2400
Max Memory Size
?
Max memory size refers to the maximum memory capacity supported by the processor.
8GB
Memory Channels
?
The number of memory channels refers to the bandwidth operation for real world application.
2
Max Memory Bandwidth
?
Max Memory bandwidth is the maximum rate at which data can be read from or stored into a semiconductor memory by the processor (in GB/s).
35.76 GB/s
ECC Memory Support
No
GPU Specifications
Integrated Graphics Model
?
An integrated GPU refers to the graphics core that is integrated into the CPU processor. Leveraging the processor's powerful computational capabilities and intelligent power efficiency management, it delivers outstanding graphics performance and a smooth application experience at a lower power consumption.
True
GPU Max Dynamic Frequency
650 MHz
GPU Base Frequency
200 MHz
Execution Units
?
The Execution Unit is the foundational building block of Intel’s graphics architecture. Execution Units are compute processors optimized for simultaneous Multi-Threading for high throughput compute power.
12
Max Resolution
3840x2160 - 30 Hz
Graphics Performance
0.14 TFLOPS
Miscellaneous
Extended Instruction Set
SSE4.2
PCIe Lanes
6
Benchmarks
Cinebench R23
Single Core
Score
439
Cinebench R23
Multi Core
Score
726
Geekbench 6
Single Core
Score
339
Geekbench 6
Multi Core
Score
474
Geekbench 5
Single Core
Score
421
Geekbench 5
Multi Core
Score
776
Passmark CPU
Single Core
Score
1033
Passmark CPU
Multi Core
Score
1416
