AMD Ryzen 7 5800H
The AMD Ryzen 7 5800H is a powerful processor designed for high-performance laptops. With 8 cores and 16 threads, it offers exceptional multi-threaded performance, making it well-suited for demanding tasks such as content creation, gaming, and productivity.
Built on TSMC's 7nm FinFET technology, the Ryzen 7 5800H is not only powerful but also energy efficient, with a total TDP of 45W. This means it can deliver impressive performance without compromising on battery life.
In addition to its impressive CPU capabilities, the Ryzen 7 5800H also features integrated AMD Radeon Graphics, providing solid visuals for gaming and multimedia tasks.
Benchmark tests showcase the processor's capabilities, with Geekbench 6 Single Core score of 1744 and a Multi-Core score of 7087, demonstrating its ability to handle both single-threaded and multi-threaded workloads with ease.
Overall, the AMD Ryzen 7 5800H offers a compelling combination of performance, energy efficiency, and integrated graphics, making it a top choice for users in need of a high-performance processor for their laptops.
Read more...
Basic
Label Name
AMD
Platform
Laptop
Launch Date
January 2021
Code Name
Cezanne
CPU Specifications
Total Cores
?
Cores is a hardware term that describes the number of independent central processing units in a single computing component (die or chip).
8
Total Threads
?
Where applicable, Intel® Hyper-Threading Technology is only available on Performance-cores.
16
Basic Frequency
3.2GHz
Max Turbo Frequency
?
Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.
Up to 4.4GHz
L2 Cache
4MB
L3 Cache
16MB
CPU Socket
?
The socket is the component that provides the mechanical and electrical connections between the processor and motherboard.
FP6
Technology
?
Lithography refers to the semiconductor technology used to manufacture an integrated circuit, and is reported in nanometer (nm), indicative of the size of features built on the semiconductor.
TSMC 7nm FinFET
TDP
45W
Max. Operating Temperature
?
Junction Temperature is the maximum temperature allowed at the processor die.
105°C
PCI Express Version
?
PCI Express Revision is the supported version of the PCI Express standard. Peripheral Component Interconnect Express (or PCIe) is a high-speed serial computer expansion bus standard for attaching hardware devices to a computer. The different PCI Express versions support different data rates.
PCIe® 3.0
Memory Specifications
Memory Type
?
Intel® processors come in four different types: Single Channel, Dual Channel, Triple Channel, and Flex Mode. Maximum supported memory speed may be lower when populating multiple DIMMs per channel on products that support multiple memory channels.
DDR4 - Up to 3200 MT/s, LPDDR4 - Up to 4266 MT/s
GPU Specifications
Integrated Graphics Model
?
An integrated GPU refers to the graphics core that is integrated into the CPU processor. Leveraging the processor's powerful computational capabilities and intelligent power efficiency management, it delivers outstanding graphics performance and a smooth application experience at a lower power consumption.
AMD Radeon™ Graphics
Graphics Frequency
?
Graphics max dynamic frequency refers to the maximum opportunistic graphics render clock frequency (in MHz) that can be supported using Intel® HD Graphics with Dynamic Frequency feature.
2000 MHz
Graphics Core Count
8
Miscellaneous
OS Support
Windows 10 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit *Operating System (OS) support will vary by manufacturer.
Benchmarks
Geekbench 6
Single Core
Score
1744
Geekbench 6
Multi Core
Score
7087
Geekbench 5
Single Core
Score
1308
Geekbench 5
Multi Core
Score
6897
Passmark CPU
Single Core
Score
3049
Passmark CPU
Multi Core
Score
21089
Compared to Other CPU
Geekbench 6 Single Core
Geekbench 6 Multi Core
Geekbench 5 Single Core
Geekbench 5 Multi Core
Passmark CPU Single Core
Passmark CPU Multi Core
