Intel Core Ultra 5 235UA processor review

Intel Core Ultra 5 235UA: The Performance of a Rare Corporate Processor

The Intel Core Ultra 5 235UA is an energy-efficient mobile processor designed for corporate laptops. It is aimed at office work, programming, and other tasks where moderate power consumption and high single-core speed are important.

The model supports Intel vPro, a set of tools for remote management and servicing of corporate computers. The performance of the vPro processor is unaffected, and the availability of the full feature set depends on the specific laptop.

In terms of frequency, cache size, integrated graphics, and power limits, the Core Ultra 5 235UA is similar to the more common Core Ultra 5 235U. However, Intel specifies a different number of cores and threads for each, so results from the 235U can only be used as a preliminary benchmark.

How Core Ultra 5 235UA Differs from Core Ultra 5 235U

For the Core Ultra 5 235UA, Intel lists 10 cores and 12 threads, specifically mentioning two low-power LP E-cores. The Core Ultra 5 235U, with a similar architecture, is claimed to be a 12-core and 14-thread processor.

Nonetheless, the maximum frequency of the P-cores, cache size, integrated graphics configuration, and declared power limits remain the same across both models. The reason for the discrepancy in the number of cores and threads in the official specifications is not explained.

Until additional data appears, the results from the two processors cannot be considered fully interchangeable.

Performance in Benchmarks

Currently, there are almost no direct results for the Core Ultra 5 235UA in Geekbench. For preliminary evaluation, laptops featuring the similar Core Ultra 5 235U can be used.

Laptop with Core Ultra 5 235U Geekbench 6 Single-Core Geekbench 6 Multi-Core
Lenovo ThinkPad X1 Carbon Gen 13 2413 10,326
HP EliteBook 6 G1i 16 2459 10,180
Dell Pro 14 Plus PB14250 2422 9,395
Lenovo ThinkPad T14 Gen 6 2420 7,931

The single-threaded results for most models hover around 2400 points. This level ensures smooth operation of Windows, browsers, office applications, and development environments.

In the multi-threaded test, the variation is much greater-roughly between 7900 and 10,300 points. The difference among laptops with the same processor exceeds 30%.

Single-threaded performance is less dependent on the overall power limit, which is why results across different models are closer together. When all cores are utilized, power and cooling constraints are more pronounced.

The ThinkPad X1 Carbon Gen 13 and HP EliteBook 6 G1i 16 score over 10,000 points. The ThinkPad T14 Gen 6, however, shows a noticeably lower multi-threaded score while having a similar single-core performance.

From the performance of the Core Ultra 5 235U, one can preliminarily expect from the version 235UA:

  • Geekbench 6 Single-Core: 2300-2450 points;
  • Geekbench 6 Multi-Core: 8000-10,000 points.

This is an estimated range and not the results of direct testing of the Core Ultra 5 235UA.

Performance in Work Tasks

The high single-core performance makes the Core Ultra 5 235UA suitable for office applications, browsers, accounting software, and development environments. The processor can also handle video conferencing, multitasking, and light photo editing.

In prolonged multi-threaded loads, the two powerful P-cores and low power limits become a noticeable constraint. For rendering, compiling large projects, and engineering calculations, it is better to choose H-series processors with a larger number of performance cores.

Integrated Graphics

The integrated Intel Graphics are suitable for workplace interfaces, video playback, and connecting external monitors. In less demanding games, it may be necessary to reduce the resolution and quality settings.

The main limitation of the Core Ultra 5 235UA remains its graphics capabilities. For modern gaming, 3D modeling, and heavy video editing, it's better to opt for a laptop with a more powerful integrated GPU or a discrete graphics card.

NPU and AI Functions

The integrated Intel AI Boost offers up to 12 TOPS and can be used for noise suppression, background blurring, and camera image processing.

This is insufficient to meet the requirements for Copilot+ PC, where an NPU with a minimum performance of 40 TOPS is required. The presence of a neural block should not be a deciding factor in choosing a laptop.

Conclusion

The Intel Core Ultra 5 235UA is suitable for corporate laptops, office work, and programming, but it is not designed for prolonged heavy workloads and modern gaming.

Based on the tests of the similar Core Ultra 5 235U, one might expect approximately 2300-2450 points in Geekbench 6 Single-Core and 8000-10,000 points in Multi-Core. Until direct results are available, this range remains an estimate.

When choosing a laptop with this processor, it is more important to consider cooling, power limits, and memory configuration than to focus on slight differences in CPU naming.

Basic

Label Name
Intel
Platform
Mobile
Launch Date
July 2025
Model Name
?
The Intel processor number is just one of several factors - along with processor brand, system configurations, and system-level benchmarks - to be considered when choosing the right processor for your computing needs.
235UA
Code Name
Products formerly Arrow Lake

CPU Specifications

Total Cores
?
Cores is a hardware term that describes the number of independent central processing units in a single computing component (die or chip).
10
Total Threads
?
Where applicable, Intel® Hyper-Threading Technology is only available on Performance-cores.
12
Performance-cores
2
Efficient-cores
8
Low Power Efficient-core Base Frequency
700 MHz
Low Power Efficient-core Max Turbo Frequency
2.4 GHz
Low Power Efficient-cores
2
Intel Virtualization Technology (VT-x)
?
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
?
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Yes
Max Turbo Frequency
?
Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.
4.9 GHz
Performance-core Base Frequency
2.0 GHz
Efficient-core Base Frequency
1.6 GHz
Efficient-core Max Turbo Frequency
?
Maximum E-core turbo frequency derived from Intel® Turbo Boost Technology.
4.1 GHz
Instruction Set Extensions
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Performance-core Max Turbo Frequency
?
Maximum P-core turbo frequency derived from Intel® Turbo Boost Technology.
4.9 GHz
Enhanced Intel SpeedStep Technology
?
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Yes
Intel Hyper-Threading Technology
?
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
Yes
Intel Turbo Boost Max Technology 3.0
?
Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.
No
Intel Turbo Boost Technology
?
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.
2.0
Cache
?
CPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.
12 MB Intel® Smart Cache
Intel AES New Instructions
?
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Yes
Technology
?
Lithography refers to the semiconductor technology used to manufacture an integrated circuit, and is reported in nanometer (nm), indicative of the size of features built on the semiconductor.
Intel 3
Processor Base Power
?
The time-averaged power dissipation that the processor is validated to not exceed during manufacturing while executing an Intel-specified high complexity workload at Base Frequency and at the junction temperature as specified in the Datasheet for the SKU segment and configuration.
15 W
Maximum Turbo Power
?
The maximum sustained (>1s) power dissipation of the processor as limited by current and/or temperature controls. Instantaneous power may exceed Maximum Turbo Power for short durations (<=10ms). Note: Maximum Turbo Power is configurable by system vendor and can be system specific.
57 W
Minimum Assured Power
12 W
Max. Operating Temperature
?
Junction Temperature is the maximum temperature allowed at the processor die.
110 °C
PCI Express Version
?
PCI Express Revision is the supported version of the PCI Express standard. Peripheral Component Interconnect Express (or PCIe) is a high-speed serial computer expansion bus standard for attaching hardware devices to a computer. The different PCI Express versions support different data rates.
4.0
Instruction Set
?
The instruction set is a hard program stored inside the CPU that guides and optimizes CPU operations. With these instruction sets, the CPU can run more efficiently. There are many manufacturers that design CPUs, which results in different instruction sets, such as the 8086 instruction set for the Intel camp and the RISC instruction set for the ARM camp. x86, ARM v8, and MIPS are all codes for instruction sets. Instruction sets can be extended; for example, x86 added 64-bit support to create x86-64. Manufacturers developing CPUs that are compatible with a certain instruction set need authorization from the instruction set patent holder. A typical example is Intel authorizing AMD, enabling the latter to develop CPUs compatible with the x86 instruction set.
64-bit
Intel 64
?
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.
Yes
Intel VT-x with Extended Page Tables (EPT)
?
Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.
Yes
PCI Express Configurations
?
PCI Express (PCIe) Configurations describe the available PCIe lane configurations that can be used to link to PCIe devices.
3x4 + 2x4 (x1,x2,x4)

Memory Specifications

Memory Type
?
Intel® processors come in four different types: Single Channel, Dual Channel, Triple Channel, and Flex Mode. Maximum supported memory speed may be lower when populating multiple DIMMs per channel on products that support multiple memory channels.
Up to LPDDR5/X 8400 MT/s
Up to DDR5 6400 MT/s
Max Memory Size
?
Max memory size refers to the maximum memory capacity supported by the processor.
128 GB
Memory Channels
?
The number of memory channels refers to the bandwidth operation for real world application.
2

GPU Specifications

GPU Name
Intel® Graphics
GPU Max Dynamic Frequency
2.05 GHz
Xe-cores
4
DirectX Support
?
DirectX* Support indicates support for a specific version of Microsoft’s collection of APIs (Application Programming Interfaces) for handling multimedia compute tasks.
12.2
Max Resolution (DP)
?
Max Resolution (DP) is the maximum resolution supported by the processor via the DP interface (24bits per pixel & 60Hz). System or device display resolution is dependent on multiple system design factors; actual resolution may be lower on your system.
7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)
?
Max Resolution (Integrated Flat Panel) is the maximum resolution supported by the processor for a device with an integrated flat panel (24bits per pixel & 60Hz). System or device display resolution is dependent on multiple system design factors; actual resolution may be lower on your device.
3840 x 2400 @ 120Hz
Max Resolution (HDMI)
?
Max Resolution (HDMI) is the maximum resolution supported by the processor via the HDMI interface (24bits per pixel & 60Hz). System or device display resolution is dependent on multiple system design factors; actual resolution may be lower on your system.
4096 x 2304 @ 60Hz (HDMI 2.1 TMDS)
7680 x 4320 @ 60Hz (HDMI 2.1 FRL)
Number of Displays Supported
4
Graphics Output
?
Graphics Output defines the interfaces available to communicate with display devices.
eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL
OpenGL Support
?
OpenGL (Open Graphics Library) is a cross-language, multi-platform API (Application Programming Interface) for rendering 2D and 3D vector graphics.
4.6
OpenCL Support
?
OpenCL (Open Computing Language) is a multi-platform API (Application Programming Interface) for heterogeneous parallel programming.
3.0
Intel Quick Sync Video
?
Intel® Quick Sync Video delivers fast conversion of video for portable media players, online sharing, and video editing and authoring.
Yes

AI Specifications

Intel Gaussian Neural Accelerator
?
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.
3.5
NPU Name
Intel® AI Boost
Intel Deep Learning Boost (Intel DL Boost) on CPU
?
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.
Yes

Interfaces and Ports

Intel Volume Management Device (VMD)
?
Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.
Yes
PCIe Lanes
20

Miscellaneous

Official Website
Intel Standard Manageability (ISM)
?
Intel® Standard Manageability is the manageability solution for Intel vPro® Essentials platforms and is a subset of Intel® AMT with out-of-band management over Ethernet and Wi-Fi, but no KVM or new life cycle management features.
Yes
Execute Disable Bit
?
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.
Yes
Intel Active Management Technology (AMT)
Yes
Intel High Definition Audio
Yes
Intel Boot Guard
?
Intel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks.
Yes
Intel Control-Flow Enforcement Technology
?
CET - Intel Control-flow Enforcement Technology (CET) helps protect against the misuse of legitimate code snippets through return-oriented programming (ROP) control-flow hijacking attacks.
Yes
Intel OS Guard
Yes
